Broadband Low Noise Amplifier

1 to 18 GHz, 28 dB Gain, 2.5 dB Noise Figure, SMA (F)
SBL-0131832630-SFSF-I1 is a low noise amplifier with a frequency range of 1.0 to 18.0 GHz. The amplifier has a small signal gain of 26 dB minimum and 28 dB typical with a gain flatness of ±2.0 dB maximum. The noise figure is 2.5 dB typical and 3.0 dB maximum. The input and output ports have a voltage standing wave ratio of 2.5:1 typical. The DC power requirement for the amplifier is +12.0 VDC /160 mA. The RF connectors are female SMA connectors.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,850.00
5 - 9 $1,665.00
10 - 24 $1,498.50

Bulk Availability


Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency1 GHz
Maximum Frequency18 GHz
Gain28 dB
Noise Figure2.5 dB
P1dB+15 dBm
Input Return Loss7 dB
Output Return Loss7 dB
DC Bias+12 VDC/160 mA
RF Input/OutputSMA (F)
