Broadband Amplifier

1 to 18 GHz, 25 dB Gain, +28 dBm P1dB, 5.0 dB Noise Figure, SMA (F)
SKU:SBB-0131832528-SFSF-E3
Availability:4 to 6 Weeks ARO
SBB-0131832528-SFSF-E3 is a broadband amplifier with a typical small signal gain of 25 dB, a nominal P1dB of +28 dBm, and a typical noise figure of 5.0 dB across the frequency range of 1.0 to 18 GHz. The DC power requirement for the amplifier is +12 VDC/500 mA. The use of a heat sink is advised to assist in cooling the device. The RF connectors are female SMA connectors. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 2 $2,750.00
3 - 4 $2,612.50
5 - 9 $2,481.88

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency1 GHz
Maximum Frequency18 GHz
Gain25 dB
P1dB+28 dBm
Psat+29 dBm
Input Return Loss12 dB
Output Return Loss10 dB
DC Bias+12 VDC/500 mA
RF Input/OutputSMA (F)
