W-Band Omnidirectional Antenna

0 dBi Gain, 90 to 100 GHz, WR-10 Waveguide
SKU:SAO-9031040060-10-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-WR10GAIN-ODA.
A 2D pattern measurement test is offered under service number FTA-WR10PATT-ODA.

CLICK HERE to read more about our antenna measurement capabilities.

SAO-9031040060-10-S1 is a W-band omnidirectional antenna that operates between 90 and 100 GHz. This vertically polarized antenna offers 360 degree azimuth coverage with 0 dBi gain and ±3 dB gain flatness. The antenna features a half power beamwidth of 60 degrees in the vertical direction.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency90 GHz
Maximum Frequency100 GHz
Gain0 dBi
Azimuth360°
3 dB Beamwidth, Vertical60°
Return Loss9 dB
InputWR-10 Waveguide
