90 Degree Coaxial Hybrid Coupler

SCZ-0520831609-SFSF-43 is a coaxial 90-degree hybrid coupler that covers the frequency range of 0.5 to 8 GHz. The nominal coupling is 3 dB and the typical insertion loss is 2.2 dB. The typical isolation of the coupler is 16 dB. The RF connectors of the coupler are female SMA connectors. The power handling of the coupler is 20 watts maximum. Other configurations, such as different connectors for input and output, are available under different model numbers.
