Absorptive SPST PIN Diode Switch

0.5 to 50 GHz, 50 dB Isolation, 2.40 mm (F)
SKU:SKS-0525035050-2F2F-A3
Availability:6 to 8 Weeks ARO
SKS-0525035050-2F2F-A3 is an absorptive PIN diode based, single pole, single throw (SPST) switch with a TTL driver that operates between 0.5 and 50 GHz. This model offers a typical insertion loss of 5.0 dB and 50 dB port-to-port isolation with a typical switching speed of 100 nanoseconds. The switch has female 2.4mm connectors for all RF ports and solder pins for DC bias and TTL control.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 4$1,850.00
5 - 9$1,665.00
10 - 24$1,498.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency0.5 GHz
Maximum Frequency50 GHz
Insertion Loss5.0 dB
Isolation50 dB
Bias±5 VDC/50 mA
Switching Speed100 ns
Switch TypeAbsorptive
RF Port2.40 mm (F)
