Broadband Amplifier

0.1 to 30 GHz, 15 dB Gain, +15 dBm P1db, 5.0 dB Noise Figure, 2.92 mm (F)
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SBB-0123031520-KFKF-S1 is a broadband amplifier with a typical small signal gain of 15 dB, a nominal P1dB of +15 dBm, and a noise figure of 5.0 dB across the frequency range of 0.1 to 30 GHz. The DC power requirement for the amplifier is +8 VDC/160 mA. The RF connectors are female K connectors. Other port configurations, such as male K connectors for either the input or output port, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
Login to view pricing

Bulk Pricing

Quantity Price
1 - 2 $2,700.00
3 - 4 $2,565.00
5 - 9 $2,436.75

Bulk Availability

1 - 2In Stock

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency0.1 GHz
Maximum Frequency30 GHz
Gain15 dB
P1dB+15 dBm
Psat+20 dBm
Input Return Loss6 dB
Output Return Loss6 dB
DC Bias+8 VDC/160 mA
RF Input/OutputK (F)
