Broadband Amplifier

0.01 to 40 GHz, 40 dB Gain, +19 dBm P1dB, 6.0 dB Noise Figure, 2.92 mm (F)
SKU:SBB-0114034019-KFKF-E3
Availability:Contact Us for Quote
SBB-0114034019-KFKF-E3 is a broadband amplifier with a minimum small signal gain of 40 dB, a nominal P1dB of +19 dBm, and a typical noise figure of 6.0 dB across the frequency range of 0.01 to 40 GHz. The DC power requirement for the amplifier is +12 VDC/400 mA. The use of a heat sink is advised to assist in cooling the device. The RF connectors are female 2.92 mm connectors. Other port configurations are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency0.01 GHz
Maximum Frequency40 GHz
Gain40 dB
P1dB+19 dBm
Psat+21 dBm
Input Return Loss8 dB
Output Return Loss8 dB
DC Bias+12 VDC/450 mA
RF Input/OutputK (F)
